EinScan-SE V2

EinScan-SE V2
(0 reviews)
Product Features

• Easier operation and higher efficiency

• can perform a single scan in 10 seconds and a complete, 360-degree scan from 1.25 to 2 min, depending on the step size selected for a full rotation of the turntable (from 8 to 180) and the HDR settings used. The multiple scans can be smoothly aligned by the pro dedicated software, besides, there’s an intuitive user interface, making for a swift and easy scanning experience. Moreover, the product is fully compatible with 3D printers, providing API access service for any brand.

• The new EinScan model can be used for a variety of different applications, such as:

• Architecture

• Art and generative design

• Reverse engineering

• Manufacturing

• AR, VR, 3D modeling

• Heritage preservation, artifact restoration

• Science and education

• Healthcare

• Scan volume: 700 Ñ… 700 Ñ… 700 mm

• One-click operation

• Single scan accuracy: up to 100 microns

₹253563.00
Out Of Stock
Notify me !
Add to wishlist Remove from wishlist Compare Ask a question Share

Guarantee Safe Checkout:

  • card
  • card
  • card
  • card

Estimated delivery time: 4-5 business days

Free shipping on all orders

Frequently Bought Together
img-product
Two Trees TS2 Engraver Enclosure With Smoke Extraction (800X800X400mm)
₹11999.00
img-product
eSUN PETG 3D Printing Filament Solid Gold, 1.75mm, Net Weight-1kg
₹1309.00
img-product
Limit switch for 4Max Pro 2.0
₹299.00
img-product
Coffee printer cartridges
₹6009.00
Total price:
₹60.00
EinScan-SE V2
Notify me !
  • Easier Operation, Faster Scanning User friendliness : needed for a single scan 8 s-Time needed for a 360-degree scan under auto-scan mode: 2 mins.
  • Compatible for Communicating with 3D Printers : Auto meshing to watertight 3D data, providing high quality 3D data for 3D printer, which can be printedby 3D printer directly. Provide API access service for any brand 3D printers
  • Automatic Software : Automatic calibration with no rigid set-up required; One-click scanning; Auto alignment and fusion for direct mesh generation;Multiple ways of alignment available turntable, feature and manual alignment provides an accuracy of 0.1mm for a single scan.
  • QUALITY : Structured light 3d scanning technology, great power of reconstruction the real geometry of the object with fine detail.
  • UPLOAD : Support third-party data sharing platform for access service. One Click Upload for Online File Archiving and Data Sharing
  • SAFETY: Visible white light, no laser, eyes secure for children.
  • Navigation : Scan accuracy,Scan volume.Scanning tips,Scanner controls,Software
  • Easier operation and higher efficiency can perform a single scan in 10 seconds and a complete, 360-degree scan from 1.
  • 25 to 2 min, depending on the step size selected for a full rotation of the turntable (from 8 to 180) and the HDR settings used.
  • The multiple scans can be smoothly aligned by the pro dedicated software, besides, there’s an intuitive user interface, making for a swift and easy scanning experience.
  • Moreover, the product is fully compatible with 3D printers, providing API access service for any brand.
  • The new EinScan model can be used for a variety of different applications, such as: Architecture Art and generative design Reverse engineering Manufacturing AR, VR, 3D modeling Heritage preservation, artifact restoration Science and education Healthcare Scan volume: 700 Ñ… 700 Ñ… 700 mm One-click operation Single scan accuracy: up to 100 microns.
  • accuracy Up to 0.1 mm :
  • Connectivity USB 3.0 :
  • Display No :
  • Manufacturer Shining 3D :
  • Manufacturer country China :
  • Outer dimensions millimeters (xyz) 570 x 210 x 210 mm :
  • Software EXScan S :
  • Weight kg 2.5 kg :
  • Technology Structured light :
  • Alignment Feature, Manual, Turntable :
  • Camera resolution 1.3 MP :
  • Computer requirements (recommended) Graphics card : Nvidia series; Graphics memory > 1G
  • Computer requirements (required) USB : 1 x USB 2.0 or 3.0; OS
  • Output formats ASC, OBJ, PLY, STL :
  • Point distance 0.17 mm ~ 0.2 mm :
  • Rotating table Yes :
  • Working range 0.29–0.48 m :
  • Scan volume max 700 x 700 x 700 mm (Fixed Scan); 200 x 200 x 200 mm (Auto Scan) :
  • Texture / Colors Yes :
